Name

ID

OBJECT_ANALOG_INPUT

0

OBJECT_ANALOG_OUTPUT

1

OBJECT_ANALOG_VALUE

2

OBJECT_BINARY_INPUT

3

OBJECT_BINARY_OUTPUT

4

OBJECT_BINARY_VALUE

5

OBJECT_CALENDAR

6

OBJECT_COMMAND

7

OBJECT_DEVICE

8

OBJECT_EVENT_ENROLLMENT

9

OBJECT_FILE

10

OBJECT_GROUP

11

OBJECT_LOOP

12

OBJECT_MULTI_STATE_INPUT

13

OBJECT_MULTI_STATE_OUTPUT

14

OBJECT_NOTIFICATION_CLASS

15

OBJECT_PROGRAM

16

OBJECT_SCHEDULE

17

OBJECT_AVERAGING

18

OBJECT_MULTI_STATE_VALUE

19

OBJECT_TRENDLOG

20

OBJECT_LIFE_SAFETY_POINT

21

OBJECT_LIFE_SAFETY_ZONE

22

OBJECT_ACCUMULATOR

23

OBJECT_PULSE_CONVERTER

24

OBJECT_EVENT_LOG

25

OBJECT_GLOBAL_GROUP

26

OBJECT_TREND_LOG_MULTIPLE

27

OBJECT_LOAD_CONTROL

28

OBJECT_STRUCTURED_VIEW

29

OBJECT_ACCESS_DOOR

30

OBJECT_TIMER

31

OBJECT_ACCESS_CREDENTIAL

32

OBJECT_ACCESS_POINT

33

OBJECT_ACCESS_RIGHTS

34

OBJECT_ACCESS_USER

35

OBJECT_ACCESS_ZONE

36

OBJECT_CREDENTIAL_DATA_INPUT

37

OBJECT_NETWORK_SECURITY

38

OBJECT_BITSTRING_VALUE

39

OBJECT_CHARACTERSTRING_VALUE

40

OBJECT_DATE_PATTERN_VALUE

41

OBJECT_DATE_VALUE

42

OBJECT_DATETIME_PATTERN_VALUE

43

OBJECT_DATETIME_VALUE

44

OBJECT_INTEGER_VALUE

45

OBJECT_LARGE_ANALOG_VALUE

46

OBJECT_OCTETSTRING_VALUE

47

OBJECT_POSITIVE_INTEGER_VALUE

48

OBJECT_TIME_PATTERN_VALUE

49

OBJECT_TIME_VALUE

50

OBJECT_NOTIFICATION_FORWARDER

51

OBJECT_ALERT_ENROLLMENT

52

OBJECT_CHANNEL

53

OBJECT_LIGHTING_OUTPUT

54

OBJECT_BINARY_LIGHTING_OUTPUT

55

MAX_ASHRAE_OBJECT_TYPE

56

OBJECT_PROPRIETARY_MIN

128

OBJECT_PROPRIETARY_MAX

1023

MAX_BACNET_OBJECT_TYPE

1024

Name

ID

PROP_ACKED_TRANSITIONS

0

PROP_ACK_REQUIRED

1

PROP_ACTION

2

PROP_ACTION_TEXT

3

PROP_ACTIVE_TEXT

4

PROP_ACTIVE_VT_SESSIONS

5

PROP_ALARM_VALUE

6

PROP_ALARM_VALUES

7

PROP_ALL

8

PROP_ALL_WRITES_SUCCESSFUL

9

PROP_APDU_SEGMENT_TIMEOUT

10

PROP_APDU_TIMEOUT

11

PROP_APPLICATION_SOFTWARE_VERSION

12

PROP_ARCHIVE

13

PROP_BIAS

14

PROP_CHANGE_OF_STATE_COUNT

15

PROP_CHANGE_OF_STATE_TIME

16

PROP_NOTIFICATION_CLASS

17

PROP_BLANK_1

18

PROP_CONTROLLED_VARIABLE_REFERENCE

19

PROP_CONTROLLED_VARIABLE_UNITS

20

PROP_CONTROLLED_VARIABLE_VALUE

21

PROP_COV_INCREMENT

22

PROP_DATE_LIST

23

PROP_DAYLIGHT_SAVINGS_STATUS

24

PROP_DEADBAND

25

PROP_DERIVATIVE_CONSTANT

26

PROP_DERIVATIVE_CONSTANT_UNITS

27

PROP_DESCRIPTION

28

PROP_DESCRIPTION_OF_HALT

29

PROP_DEVICE_ADDRESS_BINDING

30

PROP_DEVICE_TYPE

31

PROP_EFFECTIVE_PERIOD

32

PROP_ELAPSED_ACTIVE_TIME

33

PROP_ERROR_LIMIT

34

PROP_EVENT_ENABLE

35

PROP_EVENT_STATE

36

PROP_EVENT_TYPE

37

PROP_EXCEPTION_SCHEDULE

38

PROP_FAULT_VALUES

39

PROP_FEEDBACK_VALUE

40

PROP_FILE_ACCESS_METHOD

41

PROP_FILE_SIZE

42

PROP_FILE_TYPE

43

PROP_FIRMWARE_REVISION

44

PROP_HIGH_LIMIT

45

PROP_INACTIVE_TEXT

46

PROP_IN_PROCESS

47

PROP_INSTANCE_OF

48

PROP_INTEGRAL_CONSTANT

49

PROP_INTEGRAL_CONSTANT_UNITS

50

PROP_ISSUE_CONFIRMED_NOTIFICATIONS

51

PROP_LIMIT_ENABLE

52

PROP_LIST_OF_GROUP_MEMBERS

53

PROP_LIST_OF_OBJECT_PROPERTY_REFERENCES

54

PROP_LIST_OF_SESSION_KEYS

55

PROP_LOCAL_DATE

56

PROP_LOCAL_TIME

57

PROP_LOCATION

58

PROP_LOW_LIMIT

59

PROP_MANIPULATED_VARIABLE_REFERENCE

60

PROP_MAXIMUM_OUTPUT

61

PROP_MAX_APDU_LENGTH_ACCEPTED

62

PROP_MAX_INFO_FRAMES

63

PROP_MAX_MASTER

64

PROP_MAX_PRES_VALUE

65

PROP_MINIMUM_OFF_TIME

66

PROP_MINIMUM_ON_TIME

67

PROP_MINIMUM_OUTPUT

68

PROP_MIN_PRES_VALUE

69

PROP_MODEL_NAME

70

PROP_MODIFICATION_DATE

71

PROP_NOTIFY_TYPE

72

PROP_NUMBER_OF_APDU_RETRIES

73

PROP_NUMBER_OF_STATES

74

PROP_OBJECT_IDENTIFIER

75

PROP_OBJECT_LIST

76

PROP_OBJECT_NAME

77

PROP_OBJECT_PROPERTY_REFERENCE

78

PROP_OBJECT_TYPE

79

PROP_OPTIONAL

80

PROP_OUT_OF_SERVICE

81

PROP_OUTPUT_UNITS

82

PROP_EVENT_PARAMETERS

83

PROP_POLARITY

84

PROP_PRESENT_VALUE

85

PROP_PRIORITY

86

PROP_PRIORITY_ARRAY

87

PROP_PRIORITY_FOR_WRITING

88

PROP_PROCESS_IDENTIFIER

89

PROP_PROGRAM_CHANGE

90

PROP_PROGRAM_LOCATION

91

PROP_PROGRAM_STATE

92

PROP_PROPORTIONAL_CONSTANT

93

PROP_PROPORTIONAL_CONSTANT_UNITS

94

PROP_PROTOCOL_CONFORMANCE_CLASS

95

PROP_PROTOCOL_OBJECT_TYPES_SUPPORTED

96

PROP_PROTOCOL_SERVICES_SUPPORTED

97

PROP_PROTOCOL_VERSION

98

PROP_READ_ONLY

99

PROP_REASON_FOR_HALT

100

PROP_RECIPIENT

101

PROP_RECIPIENT_LIST

102

PROP_RELIABILITY

103

PROP_RELINQUISH_DEFAULT

104

PROP_REQUIRED

105

PROP_RESOLUTION

106

PROP_SEGMENTATION_SUPPORTED

107

PROP_SETPOINT

108

PROP_SETPOINT_REFERENCE

109

PROP_STATE_TEXT

110

PROP_STATUS_FLAGS

111

PROP_SYSTEM_STATUS

112

PROP_TIME_DELAY

113

PROP_TIME_OF_ACTIVE_TIME_RESET

114

PROP_TIME_OF_STATE_COUNT_RESET

115

PROP_TIME_SYNCHRONIZATION_RECIPIENTS

116

PROP_UNITS

117

PROP_UPDATE_INTERVAL

118

PROP_UTC_OFFSET

119

PROP_VENDOR_IDENTIFIER

120

PROP_VENDOR_NAME

121

PROP_VT_CLASSES_SUPPORTED

122

PROP_WEEKLY_SCHEDULE

123

PROP_ATTEMPTED_SAMPLES

124

PROP_AVERAGE_VALUE

125

PROP_BUFFER_SIZE

126

PROP_CLIENT_COV_INCREMENT

127

PROP_COV_RESUBSCRIPTION_INTERVAL

128

PROP_CURRENT_NOTIFY_TIME

129

PROP_EVENT_TIME_STAMPS

130

PROP_LOG_BUFFER

131

PROP_LOG_DEVICE_OBJECT_PROPERTY

132

PROP_ENABLE

133

PROP_LOG_INTERVAL

134

PROP_MAXIMUM_VALUE

135

PROP_MINIMUM_VALUE

136

PROP_NOTIFICATION_THRESHOLD

137

PROP_PREVIOUS_NOTIFY_TIME

138

PROP_PROTOCOL_REVISION

139

PROP_RECORDS_SINCE_NOTIFICATION

140

PROP_RECORD_COUNT

141

PROP_START_TIME

142

PROP_STOP_TIME

143

PROP_STOP_WHEN_FULL

144

PROP_TOTAL_RECORD_COUNT

145

PROP_VALID_SAMPLES

146

PROP_WINDOW_INTERVAL

147

PROP_WINDOW_SAMPLES

148

PROP_MAXIMUM_VALUE_TIMESTAMP

149

PROP_MINIMUM_VALUE_TIMESTAMP

150

PROP_VARIANCE_VALUE

151

PROP_ACTIVE_COV_SUBSCRIPTIONS

152

PROP_BACKUP_FAILURE_TIMEOUT

153

PROP_CONFIGURATION_FILES

154

PROP_DATABASE_REVISION

155

PROP_DIRECT_READING

156

PROP_LAST_RESTORE_TIME

157

PROP_MAINTENANCE_REQUIRED

158

PROP_MEMBER_OF

159

PROP_MODE

160

PROP_OPERATION_EXPECTED

161

PROP_SETTING

162

PROP_SILENCED

163

PROP_TRACKING_VALUE

164

PROP_ZONE_MEMBERS

165

PROP_LIFE_SAFETY_ALARM_VALUES

166

PROP_MAX_SEGMENTS_ACCEPTED

167

PROP_PROFILE_NAME

168

PROP_AUTO_SLAVE_DISCOVERY

169

PROP_MANUAL_SLAVE_ADDRESS_BINDING

170

PROP_SLAVE_ADDRESS_BINDING

171

PROP_SLAVE_PROXY_ENABLE

172

PROP_LAST_NOTIFY_RECORD

173

PROP_SCHEDULE_DEFAULT

174

PROP_ACCEPTED_MODES

175

PROP_ADJUST_VALUE

176

PROP_COUNT

177

PROP_COUNT_BEFORE_CHANGE

178

PROP_COUNT_CHANGE_TIME

179

PROP_COV_PERIOD

180

PROP_INPUT_REFERENCE

181

PROP_LIMIT_MONITORING_INTERVAL

182

PROP_LOGGING_OBJECT

183

PROP_LOGGING_RECORD

184

PROP_PRESCALE

185

PROP_PULSE_RATE

186

PROP_SCALE

187

PROP_SCALE_FACTOR

188

PROP_UPDATE_TIME

189

PROP_VALUE_BEFORE_CHANGE

190

PROP_VALUE_SET

191

PROP_VALUE_CHANGE_TIME

192

PROP_ALIGN_INTERVALS

193

PROP_INTERVAL_OFFSET

195

PROP_LAST_RESTART_REASON

196

PROP_LOGGING_TYPE

197

PROP_RESTART_NOTIFICATION_RECIPIENTS

202

PROP_TIME_OF_DEVICE_RESTART

203

PROP_TIME_SYNCHRONIZATION_INTERVAL

204

PROP_TRIGGER

205

PROP_UTC_TIME_SYNCHRONIZATION_RECIPIENTS

206

PROP_NODE_SUBTYPE

207

PROP_NODE_TYPE

208

PROP_STRUCTURED_OBJECT_LIST

209

PROP_SUBORDINATE_ANNOTATIONS

210

PROP_SUBORDINATE_LIST

211

PROP_ACTUAL_SHED_LEVEL

212

PROP_DUTY_WINDOW

213

PROP_EXPECTED_SHED_LEVEL

214

PROP_FULL_DUTY_BASELINE

215

PROP_REQUESTED_SHED_LEVEL

218

PROP_SHED_DURATION

219

PROP_SHED_LEVEL_DESCRIPTIONS

220

PROP_SHED_LEVELS

221

PROP_STATE_DESCRIPTION

222

PROP_DOOR_ALARM_STATE

226

PROP_DOOR_EXTENDED_PULSE_TIME

227

PROP_DOOR_MEMBERS

228

PROP_DOOR_OPEN_TOO_LONG_TIME

229

PROP_DOOR_PULSE_TIME

230

PROP_DOOR_STATUS

231

PROP_DOOR_UNLOCK_DELAY_TIME

232

PROP_LOCK_STATUS

233

PROP_MASKED_ALARM_VALUES

234

PROP_SECURED_STATUS

235

PROP_ABSENTEE_LIMIT

244

PROP_ACCESS_ALARM_EVENTS

245

PROP_ACCESS_DOORS

246

PROP_ACCESS_EVENT

247

PROP_ACCESS_EVENT_AUTHENTICATION_FACTOR

248

PROP_ACCESS_EVENT_CREDENTIAL

249

PROP_ACCESS_EVENT_TIME

250

PROP_ACCESS_TRANSACTION_EVENTS

251

PROP_ACCOMPANIMENT

252

PROP_ACCOMPANIMENT_TIME

253

PROP_ACTIVATION_TIME

254

PROP_ACTIVE_AUTHENTICATION_POLICY

255

PROP_ASSIGNED_ACCESS_RIGHTS

256

PROP_AUTHENTICATION_FACTORS

257

PROP_AUTHENTICATION_POLICY_LIST

258

PROP_AUTHENTICATION_POLICY_NAMES

259

PROP_AUTHENTICATION_STATUS

260

PROP_AUTHORIZATION_MODE

261

PROP_BELONGS_TO

262

PROP_CREDENTIAL_DISABLE

263

PROP_CREDENTIAL_STATUS

264

PROP_CREDENTIALS

265

PROP_CREDENTIALS_IN_ZONE

266

PROP_DAYS_REMAINING

267

PROP_ENTRY_POINTS

268

PROP_EXIT_POINTS

269

PROP_EXPIRY_TIME

270

PROP_EXTENDED_TIME_ENABLE

271

PROP_FAILED_ATTEMPT_EVENTS

272

PROP_FAILED_ATTEMPTS

273

PROP_FAILED_ATTEMPTS_TIME

274

PROP_LAST_ACCESS_EVENT

275

PROP_LAST_ACCESS_POINT

276

PROP_LAST_CREDENTIAL_ADDED

277

PROP_LAST_CREDENTIAL_ADDED_TIME

278

PROP_LAST_CREDENTIAL_REMOVED

279

PROP_LAST_CREDENTIAL_REMOVED_TIME

280

PROP_LAST_USE_TIME

281

PROP_LOCKOUT

282

PROP_LOCKOUT_RELINQUISH_TIME

283

PROP_MASTER_EXEMPTION

284

PROP_MAX_FAILED_ATTEMPTS

285

PROP_MEMBERS

286

PROP_MUSTER_POINT

287

PROP_NEGATIVE_ACCESS_RULES

288

PROP_NUMBER_OF_AUTHENTICATION_POLICIES

289

PROP_OCCUPANCY_COUNT

290

PROP_OCCUPANCY_COUNT_ADJUST

291

PROP_OCCUPANCY_COUNT_ENABLE

292

PROP_OCCUPANCY_EXEMPTION

293

PROP_OCCUPANCY_LOWER_LIMIT

294

PROP_OCCUPANCY_LOWER_LIMIT_ENFORCED

295

PROP_OCCUPANCY_STATE

296

PROP_OCCUPANCY_UPPER_LIMIT

297

PROP_OCCUPANCY_UPPER_LIMIT_ENFORCED

298

PROP_PASSBACK_EXEMPTION

299

PROP_PASSBACK_MODE

300

PROP_PASSBACK_TIMEOUT

301

PROP_POSITIVE_ACCESS_RULES

302

PROP_REASON_FOR_DISABLE

303

PROP_SUPPORTED_FORMATS

304

PROP_SUPPORTED_FORMAT_CLASSES

305

PROP_THREAT_AUTHORITY

306

PROP_THREAT_LEVEL

307

PROP_TRACE_FLAG

308

PROP_TRANSACTION_NOTIFICATION_CLASS

309

PROP_USER_EXTERNAL_IDENTIFIER

310

PROP_USER_INFORMATION_REFERENCE

311

PROP_USER_NAME

317

PROP_USER_TYPE

318

PROP_USES_REMAINING

319

PROP_ZONE_FROM

320

PROP_ZONE_TO

321

PROP_ACCESS_EVENT_TAG

322

PROP_GLOBAL_IDENTIFIER

323

PROP_VERIFICATION_TIME

326

PROP_BASE_DEVICE_SECURITY_POLICY

327

PROP_DISTRIBUTION_KEY_REVISION

328

PROP_DO_NOT_HIDE

329

PROP_KEY_SETS

330

PROP_LAST_KEY_SERVER

331

PROP_NETWORK_ACCESS_SECURITY_POLICIES

332

PROP_PACKET_REORDER_TIME

333

PROP_SECURITY_PDU_TIMEOUT

334

PROP_SECURITY_TIME_WINDOW

335

PROP_SUPPORTED_SECURITY_ALGORITHM

336

PROP_UPDATE_KEY_SET_TIMEOUT

337

PROP_BACKUP_AND_RESTORE_STATE

338

PROP_BACKUP_PREPARATION_TIME

339

PROP_RESTORE_COMPLETION_TIME

340

PROP_RESTORE_PREPARATION_TIME

341

PROP_BIT_MASK

342

PROP_BIT_TEXT

343

PROP_IS_UTC

344

PROP_GROUP_MEMBERS

345

PROP_GROUP_MEMBER_NAMES

346

PROP_MEMBER_STATUS_FLAGS

347

PROP_REQUESTED_UPDATE_INTERVAL

348

PROP_COVU_PERIOD

349

PROP_COVU_RECIPIENTS

350

PROP_EVENT_MESSAGE_TEXTS

351

PROP_EVENT_MESSAGE_TEXTS_CONFIG

352

PROP_EVENT_DETECTION_ENABLE

353

PROP_EVENT_ALGORITHM_INHIBIT

354

PROP_EVENT_ALGORITHM_INHIBIT_REF

355

PROP_TIME_DELAY_NORMAL

356

PROP_RELIABILITY_EVALUATION_INHIBIT

357

PROP_FAULT_PARAMETERS

358

PROP_FAULT_TYPE

359

PROP_LOCAL_FORWARDING_ONLY

360

PROP_PROCESS_IDENTIFIER_FILTER

361

PROP_SUBSCRIBED_RECIPIENTS

362

PROP_PORT_FILTER

363

PROP_AUTHORIZATION_EXEMPTIONS

364

PROP_ALLOW_GROUP_DELAY_INHIBIT

365

PROP_CHANNEL_NUMBER

366

PROP_CONTROL_GROUPS

367

PROP_EXECUTION_DELAY

368

PROP_LAST_PRIORITY

369

PROP_WRITE_STATUS

370

PROP_PROPERTY_LIST

371

PROP_SERIAL_NUMBER

372

PROP_BLINK_WARN_ENABLE

373

PROP_DEFAULT_FADE_TIME

374

PROP_DEFAULT_RAMP_RATE

375

PROP_DEFAULT_STEP_INCREMENT

376

PROP_EGRESS_TIME

377

PROP_IN_PROGRESS

378

PROP_INSTANTANEOUS_POWER

379

PROP_LIGHTING_COMMAND

380

PROP_LIGHTING_COMMAND_DEFAULT_PRIORITY

381

PROP_MAX_ACTUAL_VALUE

382

PROP_MIN_ACTUAL_VALUE

383

PROP_POWER

384

PROP_TRANSITION

385

PROP_EGRESS_ACTIVE

386

PROP_INTERFACE_VALUE

387

PROP_FAULT_HIGH_LIMIT

388

PROP_FAULT_LOW_LIMIT

389

PROP_LOW_DIFF_LIMIT

390

PROP_STRIKE_COUNT

391

PROP_TIME_OF_STRIKE_COUNT_RESET

392

PROP_DEFAULT_TIMEOUT

393

PROP_INITIAL_TIMEOUT

394

PROP_LAST_STATE_CHANGE

395

PROP_STATE_CHANGE_VALUES

396

PROP_TIMER_RUNNING

397

PROP_TIMER_STATE

398

PROP_COMMAND_TIME_ARRAY

430

PROP_CURRENT_COMMAND_PRIORITY

431

PROP_LAST_COMMAND_TIME

432

PROP_VALUE_SOURCE

433

PROP_VALUE_SOURCE_ARRAY

434

MAX_BACNET_PROPERTY_ID

4194303
